HIGRACE supplies marine anchoring and docking hardware, including anchors, chains, deck fittings, and mooring hardware, for distributors, boat builders, and marine hardware importers.
hook: elec. galv. wheel: nylon
| Number | Size (in) | For Rope Dia. (mm) | WLL (lbs) | Weight (kg) |
| 501003 | 3″ | 6 | 500 | 0.45 |
| 501004 | 4″ | 9 | 1000 | 0.80 |
| 501005 | 5″ | 12 | 1200 | 1.50 |
| 501006 | 6″ | 14 | 1800 | 2.28 |
| 501008 | 8″ | 18 | 2800 | 4.10 |
| 501010 | 10″ | 22 | 4000 | 7.25 |
hook: elec. galv. wheel: nylon
| Number | Size (in) | For Rope Dia. (mm) | WLL (lbs) | Weight (kg) |
| 502003 | 3″ | 6 | 500 | 0.82 |
| 502004 | 4″ | 9 | 1000 | 1.35 |
| 502005 | 5″ | 12 | 1200 | 2.30 |
| 502006 | 6″ | 14 | 1800 | 3.90 |
| 502008 | 8″ | 18 | 2800 | 7.50 |
| 502010 | 10″ | 22 | 4000 | 11.0 |
hook: elec. galv. wheel: stee
| Number | Size (in) | For Rope Dia. (mm) | WLL (lbs) | Weight (kg) |
| 505003 | 3″ | 10 | 500 | 0.45 |
| 505004 | 4″ | 12 | 1000 | 0.80 |
| 505005 | 5″ | 16 | 1200 | 1.50 |
| 505006 | 6″ | 20 | 1800 | 2.28 |
| 505008 | 8″ | 25 | 2800 | 4.10 |
| 505010 | 10″ | 28 | 4000 | 7.25 |
hook: elec. galv. wheel: stee
| Number | Size (in) | For Rope Dia. (mm) | WLL (lbs) | Weight (kg) |
| 506003 | 3″ | 10 | 500 | 0.80 |
| 506004 | 4″ | 12 | 1000 | 1.36 |
| 506005 | 5″ | 16 | 1200 | 2.16 |
| 506006 | 6″ | 20 | 1800 | 3.86 |
| 506008 | 8″ | 25 | 2800 | 6.35 |
| 506010 | 10″ | 28 | 4000 | 10.9 |
swivel: elec. galv. wheel: nylon
| Number | Size (in) | For Rope Dia. (mm) | WLL (lbs) | Weight (kg) |
| 501503 | 3″ | 6 | 500 | 0.45 |
| 501504 | 4″ | 9 | 1000 | 0.80 |
| 501505 | 5″ | 12 | 1200 | 1.48 |
| 501506 | 6″ | 14 | 1800 | 2.30 |
| 501508 | 8″ | 18 | 2800 | 4.26 |
| 501510 | 10″ | 22 | 4000 | 7.25 |
swivel: elec. galv. wheel: nylon
| Number | Size (in) | For Rope Dia. (mm) | WLL (lbs) | Weight (kg) |
| 502503 | 3″ | 6 | 500 | 0.82 |
| 502504 | 4″ | 9 | 1000 | 1.35 |
| 502505 | 5″ | 12 | 1200 | 2.30 |
| 502506 | 6″ | 14 | 1800 | 3.90 |
| 502508 | 8″ | 18 | 2800 | 7.50 |
| 502510 | 10″ | 22 | 4000 | 11.0 |
Find more HIGRACE stainless steel hardware solutions to complete your marine, rigging, fastening, and industrial sourcing needs.
