HIGRACE supplies marine anchoring and docking hardware, including anchors, chains, deck fittings, and mooring hardware, for distributors, boat builders, and marine hardware importers.
marine grade / rust proof / corrosion resistant/stainless steel A4 / SS316 / AISI316
| Number | Size (mm) | Length (mm) | Width (mm) | Safe Working Load (lbs) |
| 161004 | 4 | 40 | 20 | 80 |
| 161005 | 5 | 50 | 25 | 100 |
| 161006 | 6 | 60 | 30 | 140 |
| 161007 | 7 | 70 | 35 | 200 |
| 161008 | 8 | 80 | 40 | 250 |
| 161009 | 9 | 90 | 45 | 280 |
| 161010 | 10 | 100 | 50 | 400 |
| 161011 | 11 | 120 | 57 | 500 |
| 161012 | 12 | 140 | 67 | 600 |
| 161013 | 13 | 160 | 74 | 700 |
steel, Elec. Galv.
| Number | Size (mm) | Length (mm) | Width (mm) | Safe Working Load (lbs) |
| 161604 | 4 | 40 | 20 | 80 |
| 161605 | 5 | 50 | 25 | 100 |
| 161606 | 6 | 60 | 30 | 140 |
| 161607 | 7 | 70 | 35 | 200 |
| 161608 | 8 | 80 | 40 | 250 |
| 161609 | 9 | 90 | 45 | 280 |
| 161610 | 10 | 100 | 50 | 400 |
| 161611 | 11 | 120 | 57 | 500 |
| 161612 | 12 | 140 | 67 | 600 |
| 161613 | 13 | 160 | 74 | 700 |
marine grade / rust proof / corrosion resistant/stainless steel A4 / SS316 / AISI316
| Number | Size (mm) | Length (mm) | Width (mm) | Safe Working Load (lbs) |
| 162004 | 4 | 40 | 20 | 80 |
| 162005 | 5 | 50 | 25 | 100 |
| 162006 | 6 | 60 | 30 | 140 |
| 162007 | 7 | 70 | 35 | 200 |
| 162008 | 8 | 80 | 40 | 250 |
| 162009 | 9 | 90 | 45 | 280 |
| 162010 | 10 | 100 | 50 | 400 |
| 162011 | 11 | 120 | 57 | 500 |
| 162012 | 12 | 140 | 67 | 600 |
| 162013 | 13 | 160 | 74 | 700 |
steel, Elec. Galv
| Number | Size (mm) | Length (mm) | Width (mm) | Safe Working Load (lbs) |
| 162604 | 4 | 40 | 20 | 80 |
| 162605 | 5 | 50 | 25 | 100 |
| 162606 | 6 | 60 | 30 | 140 |
| 162607 | 7 | 70 | 35 | 200 |
| 162608 | 8 | 80 | 40 | 250 |
| 162609 | 9 | 90 | 45 | 280 |
| 162610 | 10 | 100 | 50 | 400 |
| 162611 | 11 | 120 | 57 | 500 |
| 162612 | 12 | 140 | 67 | 600 |
| 162613 | 13 | 160 | 74 | 700 |
marine grade / rust proof / corrosion resistant/stainless steel A4 / SS316 / AISI316
| Number | Size (mm) | Length (mm) | Width (mm) | Safe Working Load (lbs) |
| 163004 | 4 | 40 | 20 | 80 |
| 163005 | 5 | 50 | 25 | 100 |
| 163006 | 6 | 60 | 30 | 140 |
| 163007 | 7 | 70 | 35 | 200 |
| 163008 | 8 | 80 | 40 | 250 |
| 163009 | 9 | 90 | 45 | 280 |
| 163010 | 10 | 100 | 50 | 400 |
| 163011 | 11 | 120 | 57 | 500 |
| 163012 | 12 | 140 | 67 | 600 |
| 163013 | 13 | 160 | 74 | 700 |
steel, Elec. Galv.
| Number | Size (mm) | Length (mm) | Width (mm) | Safe Working Load (lbs) |
| 163604 | 4 | 40 | 20 | 80 |
| 163605 | 5 | 50 | 25 | 100 |
| 163606 | 6 | 60 | 30 | 140 |
| 163607 | 7 | 70 | 35 | 200 |
| 163608 | 8 | 80 | 40 | 250 |
| 163609 | 9 | 90 | 45 | 280 |
| 163610 | 10 | 100 | 50 | 400 |
| 163611 | 11 | 120 | 57 | 500 |
| 163612 | 12 | 140 | 67 | 600 |
| 163613 | 13 | 160 | 74 | 700 |
marine grade / rust proof / corrosion resistant/stainless steel A4 / SS316 / AISI316
| Number | Size (mm) | Length (mm) | Width (mm) | Safe Working Load (lbs) |
| 164004 | 4 | 40 | 20 | 80 |
| 164005 | 5 | 50 | 25 | 100 |
| 164006 | 6 | 60 | 30 | 140 |
| 164007 | 7 | 70 | 35 | 200 |
| 164008 | 8 | 80 | 40 | 250 |
| 164009 | 9 | 90 | 45 | 280 |
| 164010 | 10 | 100 | 50 | 400 |
| 164011 | 11 | 120 | 57 | 500 |
| 164012 | 12 | 140 | 67 | 600 |
| 164013 | 13 | 160 | 74 | 700 |
steel, Elec. Galv.
| Number | Size (mm) | Length (mm) | Width (mm) | Safe Working Load (lbs) |
| 164604 | 4 | 40 | 20 | 80 |
| 164605 | 5 | 50 | 25 | 100 |
| 164606 | 6 | 60 | 30 | 140 |
| 164607 | 7 | 70 | 35 | 200 |
| 164608 | 8 | 80 | 40 | 250 |
| 164609 | 9 | 90 | 45 | 280 |
| 164610 | 10 | 100 | 50 | 400 |
| 164611 | 11 | 120 | 57 | 500 |
| 164612 | 12 | 140 | 67 | 600 |
| 164613 | 13 | 160 | 74 | 700 |
